SKU: A0000901

10MH | MIDRANGE 10'' SPEAKER 1000W | COIL 8ohm

Name: 10MH | MIDRANGE 10'' SPEAKER 1000W | COIL 8ohm
SKU: A0000901
Price: 256.05 USD
Availability: InStock

No reviews yet. Bought this? Write the first review

$256.05

Shipping calculated at checkout.

Shipping & delivery

Usually ships in 2–3 business days unless a different lead time is shown on this page. Shipping cost is calculated at checkout (UPS or USPS to the contiguous U.S.).

Shipping policy · Returns · Fitment questions? (561) 207-7988

Delivery and Shipping

Standard order processing is 2–3 business days unless this product or your order confirmation states a different lead time. Custom-built, made-to-order, backorder, and pre-order items follow their stated lead times.

Enclosures and subwoofer boxes ship for $50 per unit. Other shipping charges are calculated at checkout. Orders outside the contiguous 48 United States may require additional shipping; we will contact you for approval before shipment.

Subwoofer boxes ship UPS Ground where available. Read our Shipping Policy and Return and Refund Policy for delivery, product-specific return windows, and warranty details.

Description

This 10-inch mid-high speaker has been designed to operate at the level of a professional mid-range audio speaker; delivering incredible sound, volume and performance. It uses an extremely light and powerful high performance ferrite magnet and a single strong 8ohm coil, allowing this speaker to deliver unmatched sound clarity.

We recommend them as the best option when you want to install your midrange speakers in any professional audio setup, and even more so in door panel installations, etc. where the weight of the speakers is often a major limitation to successfully achieve the ideal sound stage with high performance and quality, so that the best listening experience is obtained.

Technical Data

Nominal Chassis Diameter	10"/255mm
Max Power	1000Watts
RMS Power	500Watts
Impedance	8ohm
Frequency Response	70-4KHz
Sensitivity(1W/1m)	98dB
Voice Coil Diameter	4"/99.2mm
Winding material	Aluminium
Magnet	Ferrite

FS Hz	70Hz
Vas	22.6 Litres
Re Ohms	5.3Ω
Qms	5.064
Qes	0.422
Qts	0.39
BL T/m	15.329
MMS(gms)	40.132
Xmas(mm)	3.5
Sd	35.299
Efficiency %	1.797
Le(1k Hz)	32.357
EBP	179Hz

Overall Diameter	10"/255mm
Bolt Circle Diameter	9.6"/244mm
Baffle cutout Diameter	9.17"/233mm
Depth	4.9“/125mm
Net Weight	7.5kgs
Shipping Weight	8.6kgs
Shipping Box	282815.5cm
