SKU: PRO-DKH1S
Sold out

2" Driver Short Horn Kit 320 Watts 2" Titanium 8-Ohm Vc (PRO-D1+PRO-HA52/BK)

No reviews yet. Bought this? Write the first review
Regular price $107.95
Shipping calculated at checkout.


Shipping & delivery

Usually ships in 2–3 business days unless a different lead time is shown on this page. Shipping cost is calculated at checkout (UPS or USPS to the contiguous U.S.).

Shipping policy · Returns · Fitment questions? (561) 207-7988

Delivery and Shipping

Standard order processing is 2–3 business days unless this product or your order confirmation states a different lead time. Custom-built, made-to-order, backorder, and pre-order items follow their stated lead times.

Enclosures and subwoofer boxes ship for $50 per unit. Other shipping charges are calculated at checkout. Orders outside the contiguous 48 United States may require additional shipping; we will contact you for approval before shipment.

Subwoofer boxes ship UPS Ground where available. Read our Shipping Policy and Return and Refund Policy for delivery, product-specific return windows, and warranty details.

Description

DS18 PRO-DKH1S 2"Bolt On Throat Compression Driver 2" Throat Titanium VC and PRO-HA52/BK Horn 640 Watts 110 Db 8 ohm Mounting Depth 4.9"

The DKH1S includes the DS18 DKH1 driver plus our newly redesigned shorty throat so you only need 4.9 inches mounting depth to mount these ear ripping drivers. The new throat is aluminum with brilliantly brushed DS18 logos and made for maximum directional efficiency. With an AES power handling of 160w and Peak at 640w you will be sure to draw everyone's attention to your audio!

Highlights

  • Aluminum "Shorty" throat with brushed DS18 logos for an amazing look and great fitment.
  • DKH1 Driver with an AES rating of 160 watts and Peak of 640w for super loud and vibrant highs with a Titanium 8 ohms voice coil.
  • 4.9 inch mounting depth and 5.3 inches total mounting depth so you don't need a large amount of mounting depth like other traditional driver and throat combinations.
Technical Details
                                               PRO-DKH1S Product Manual
Throat Diameter 2"/50.8mm
Installation Type Bolt-on
Nominal Impedance 8 Ohms
Program Power Handling 320W
Peak Power Handling 640W
AES Power Handling 160W
Sensitivity 111dB
Frequency Response 630Hz-20KHz
Recommended HI Pass Crossover 900 Hz
Motor
Voice Coil Diameter 2.03"/51mm
Voice Coil Former Material Kapton
Winding Material CCA
Diaphragm Material Titanium
Magnet Material Ferrite
Magnet Weight 35oz
Measurements
Overall Diameter 7"/180mm
Overall Depth 5.3"/134.7mm
Bolt Pattern/Type 5.5mm hole-6.3"/161 mm Diameter
Mounting Depth 4.9"/125.8mm
Mounting Hole Diameter 5.7"/145mmm
