2003-2007 Cummins 5.9L Hamilton Cams Fire Ring Gasket .056" (07-g-5.9f)
2003-2007 Cummins 5.9L Hamilton Cams Fire Ring Gasket .056" (07-g-5.9f) is backordered and will ship as soon as it is back in stock.
Confirm vehicle fitment
Confirm vehicle fitment
Confirm fitment before ordering. Match the year, make, model, trim, engine, drivetrain and selected options shown on this page. If any detail is unclear, search your exact vehicle or contact us before checkout.
Shipping expectations
Shipping expectations
Availability and processing time can vary by manufacturer. Available shipping choices and charges appear at checkout. Tracking is emailed after shipment. Oversized, special-order and supplier-shipped items can require additional processing time.
Returns and cancellations
Returns and cancellations
Please review eligibility before purchase. Installed, used, electronic, custom, special-order and clearance items may have return restrictions. Contact us promptly if you need to change or cancel an order.
What’s included
What’s included
The product description and selected variant determine what is included. Items shown in lifestyle or installation photos are not included unless they are specifically listed in the description.
2003-2007 Cummins 5.9L Hamilton Cams Fire Ring Gasket .056" (0...
2003-2007 Cummins 5.9L Hamilton Cams Fire Ring Gasket .056" (07-g-5.9f) is backordered and will ship as soon as it is back in stock.
Buy with confidence
Verify fitment, selected options, availability and included components before checkout. Secure payment options and order confirmation are provided at checkout.
Description
Description
Upgrade your 5.9L Cummins engine with our premium Fire Ring Gasket, specifically designed to handle high cylinder pressures. Ideal for both street performance and competition builds, this gasket offers superior sealing and durability—especially when paired with proper machining, studs, and installation techniques.
Gasket Specifications
- Thickness: .056″ (1.4 mm)
- Wire Size: .105″
- Bore Diameter: 4.560″
- Groove Radius: .0120″ radiused groove in the head to a depth of .032″–.033″
Recommended Installation Guidelines
1. Machining for Flatness
- For best results, have both the head and block machined to ensure a perfectly flat sealing surface.
- Engines under 800 HP: Cutting grooves in just the head
- Be sure to run 625 studs on vehicles over 800hp
2. Use a Radiused Cutter
- We strongly recommend a radiused cutter for all groove installations to achieve optimal sealing with the fire ring.
3. Proper Stud Installation & Lubrication
- Studs are a must for reliable clamping force—our competition gasket requires studs to handle elevated boost levels.
- Apply liberal lubrication on the nut, washer, and threads to ensure even clamp load.
- Never exceed manufacturer torque limits—fasteners at full torque contain immense potential energy.
4. Torque Procedure
- Initial Torque: 130 ft-lb for startup.
- Retorque Hot: After reaching operating temperature, retorque the studs while the engine is still warm.
- Check Valve Lash: Each retorque will further compress the gasket, affecting valve lash—always re-adjust as needed.
Why Choose Our Fire Ring Gasket?
- Engineered for High Cylinder Pressures: Superior sealing under extreme conditions.
- Long-Lasting Performance: Proven to handle high horsepower builds beyond 800 HP.
- Optimal Grooving & Clamping: Designed for precision machining and consistent stud clamp load.
- Enhanced Reliability: Reduce the risk of head-gasket failure in demanding diesel applications.
