3S-122 | 12'' 3000W MAX. | DUAL 2Ω
3S-122 is a powerful 12" inch coil 2x2 ohm car subwoofer speaker.
It has a structural design that allows it to be functional and efficient, providing great resistance to prolonged use in a safe way and at the same time offering excellent sound. This subwoofer is made with:
- 12inch Black texture finish die-casting basket.
- Fiber reinforced paper cone.
- Foam surrounds silver stitching.
- 3'' 4-layer high temperature resistant CCA wire voice coil.
- Paper dust cap.
- Triple stacked high energy 234 Oz magnets.
- Direct cooling design T-yoke with black anodized treatment.
- Double black spider with mirrored layout.
- 4GA copper push ing terminal.
**Product Exclusive to USA**
Technical Data
|
Model |
3S-122 |
|
Voice Coil Diameter inch |
3’’ |
|
Impedance Ohm |
2X2 |
|
Re Ohm |
4 |
|
FS Hz |
37.566 |
|
Qms |
4.751 |
|
Qes |
0.513 |
|
Qts |
0.463 |
|
Vas Liter |
28.626 |
|
Cms |
79.763u |
|
MMS gr |
225.031 |
|
Xmax mm |
18.5 |
|
SPL(1w/1m) |
86.6 |
|
BL TESLA M |
20.351 |
|
Power W RMS |
1500 |
|
Max Power |
3000 |
