AudioControl Altitude A800.1 | 8000W RMS Monoblock Amplifier
AudioControl Altitude A800.1 | 8000W RMS Monoblock Amplifier is backordered and will ship as soon as it is back in stock.
Confirm vehicle fitment
Confirm vehicle fitment
Confirm fitment before ordering. Match the year, make, model, trim, engine, drivetrain and selected options shown on this page. If any detail is unclear, search your exact vehicle or contact us before checkout.
Shipping expectations
Shipping expectations
Availability and processing time can vary by manufacturer. Available shipping choices and charges appear at checkout. Tracking is emailed after shipment. Oversized, special-order and supplier-shipped items can require additional processing time.
Returns and cancellations
Returns and cancellations
Please review eligibility before purchase. Installed, used, electronic, custom, special-order and clearance items may have return restrictions. Contact us promptly if you need to change or cancel an order.
What’s included
What’s included
The product description and selected variant determine what is included. Items shown in lifestyle or installation photos are not included unless they are specifically listed in the description.
AudioControl Altitude A800.1 | 8000W RMS Monoblock Amplifier
AudioControl Altitude A800.1 | 8000W RMS Monoblock Amplifier is backordered and will ship as soon as it is back in stock.
Buy with confidence
Verify fitment, selected options, availability and included components before checkout. Secure payment options and order confirmation are provided at checkout.
Description
Description
- The power supply circuitry adopts advanced pulse width modulator integrated circuits that are designed to offer improved performance and efficiency.
- Designed with Advanced HEXFET® Power MOSFETs from International Rectifier that utilize advanced processing techniques to achieve extremely low on-resistance and reliable fast switching speed.
- Premium Toroidal Transformer for optimal electrical efficiency and minimal signal distortion.
- Premium Low ESR capacitors for minimal power loss and reduced internal heating.
- Precision metal potentiometers for precise tuning and sturdy construction
- Features 500V Class X2 capacitors with self-healing properties for high-frequency, high-current protection, ensuring low-loss AC peak surge and MOSFET protection.
- High-efficiency Ferrite Core Inductor power output filters provide low current eddy losses over frequencies with high permeability.
- High-performance class D intelligent driver IC with PWM modulator and protection with HEXFET Power MOSFET for abundant power and high efficiency.
FEATURES
-
High/Low Input Modes
-
GTO™ Signal Sense
-
Linkwitz-Riley Crossovers
-
Start-Stop Compliant
-
High Power Output in a Sleek Chassis
-
ParaBASS® Low Frequency Contouring
-
Valet Mode Option
-
Optional Remote Level Control (ACR-1)
- EV Compliant up to 17V
- Spike Mode Enabled
SPECIFICATIONS
INPUTS
- Preamp Inputs: 2
- Line-Level Inputs: 6 V max
- Speaker-Level Inputs: 20 V max
OUTPUTS
- Rated Continuous (RMS) Power at 14.4V:
-
400W x 1 @ 4Ω
-
600W X 1 @ 2Ω
- 800W x 1 @ 1.33Ω
-
400W x 1 @ 4Ω
Remote Level Control
- ACR-1 (optional)
WEIGHTS & DIMENSIONS
- DIMENSIONS: 10.9” W x 6.7” D x 2.1” H
- WEIGHT: 6.05 lbs
PERFORMANCE
- S/N Ratio (ref: rated power): 110.2 dBA
- THD+N: <0.14%
- Power / Ground Wire Gauge: 4 AWG
- Recommended Fuse rating: 100A
- Valet Mode: Yes
- Subsonic Filter: Variable
- Linkwitz-Riley X-Over:
-
- Low Pass
- Freq. Range: 60 Hz to 120 Hz
- Bass Processing: ParaBASS®
