Description
Description
The aluminum bodied Performance Series 2.0 Reservoir smooth body shock delivers FOX's industry leading and race dominating performance in an affordable, hassle-free bolt on package. Its heat reducing design includes a metal impacted clear anodized aluminum shock body that dissipates heat faster than a conventional steel body shock.
Its external reservoir allows for increase oil and nitrogen capacity while delivering a striking race look. The included black anodized reservoir mounting clamp and other components are CNC machined from 6061-T6 aluminum. The race developed high flow damping piston matched with application specific valving provides the Performance Series 2.0 Reservoir shock a predicable ride quality capable of handling the roughest road conditions.
| Part Number Options | Lift/Lowered | Position | Item | Quantity | Extended Length | Compressed Length | Travel | Top Mount | Bottom Mount | Reservoir | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 985-24-174 | 0-1" Lift | Rear | Shock Absorber | 2 | 30.05" | 18.45" | 11.6" | EYELET | EYELET/SLEEVE | Internal Floating Piston (IFP) | Aluminum |
|
985-24-149 |
1.5-3.5" Lift | Rear | Shock Absorber | 2 | 32.75" | 20.15" | 12.6" | ||||
|
985-24-150 |
4-6" Lift | Rear | Shock Absorber | 2 | 34.95" | 21.35" | 13.6" |
| Body | 2.0” Impact extruded and CNC machined 6061-T6 clear anodized aluminum one-piece body resists rust over time |
|---|---|
| Body Plating | Clear-anodized for a durable finish |
| Reservoir | Internal IFP mono-tube reservoir design |
| Components | Black-anodized, CNC-machined 6061-T6 billet aluminum |
| Shaft | 5/8" hard chrome plated heat-treated alloy steel |
| Piston | Race-developed high-flow piston design |
| Valving | Application-specific valving to maximize performance |
| Seals | Redundant sealing pack system main seal, wiper seal, scraper seal |
| Bushings | Quiet nitrile rubber allows for increased suspension articulation |
Fitment & installation
Fitment & installation
Check the selected part against your vehicle. Need help? Call (561) 207-7988.
Selected part: 985-24-174
Loading vehicle fitment…
Read FOX’s application notes for part 987-24-001 (rear shock)
