Eminence Kappa Pro-10A 10" Professional Series Speaker
Eminence Kappa Pro-10A 10" Professional Series Speaker is backordered and will ship as soon as it is back in stock.
Buy with confidence
Verify fitment, selected options, availability and included components before checkout. Secure payment options and order confirmation are provided at checkout.
Description
Description
| SPECIFICATION | |
| Nominal Basket Diameter | 10", 254 mm |
| Nominal Impedance* | 8 Ω |
| Power Rating* | |
| Program Power | 1000 W |
| Watts | 500 W |
| Resonance | 46 Hz |
| Usable Frequency Range | 102 Hz - 2 kHz |
| Sensitivity* | 97 dB |
| Magnet Weight | 80 oz. |
| Gap Height | 0.375", 9.5 mm |
| Voice Coil Diameter | 3", 76 mm |
| THIELE & SMALL PARAMETERS | |
| Resonant Frequency (fs) | 46 Hz |
| DC Resistance (Re) | 6.5 Ω |
| Coil Inductance (Le) | 1.15m H |
| Mechanical Q (Qms) | 10.1 |
| Electromagnetic Q (Qes) | 0.2 |
| Total Q (Qts) | 0.2 |
| Compliance Equivalent Volume (Vas) | 52.2 liters / 1.84 cu.ft. |
| Peak Diaphragm Displacement Volume (Vd) | 110 cc |
| Mechanical Compliance of Suspension (Cms) | 0.31 mm/N |
| BL Product (BL) | 18.8 T-M |
| Diaphragm Mass Inc. Airload (MMs) | 38 grams |
| Efficiency Bandwidth Product (EBP) | 230 |
| Maximum Linear Excursion (Xmax) | 3.2 mm |
| Surface Area of Cone (Sd) | 344.9 cm2 |
| Maximum Mechanical Limit (Xlim) | 10.9 mm |
| MOUNTING INFORMATION | |
| Recommended Enclosure Volume | |
| Sealed | 7-9.9 liters / 0.25-0.35 cu.ft. |
| Vented | 12-28 liters / 0.43-1 cu.ft. |
| Driver Volume Displaced | 0.061 cu.ft. / 1.72 liters |
| Overall Diameter | 10.25", 260.4 mm |
| Baffle Hole Diameter | 9.13", 231.9 mm |
| Front Sealing Gasket | Yes |
| Rear Sealing Gasket | Yes |
| Mounting Holes Diameter | 0.27", 6.9mm |
| Mounting Holes B.C.D. | 9.75", 247.7mm |
| Depth | 4.33", 110 mm |
| Net Weight | 15.3 lbs, 6.94 kg |
| Shipping Weight | 16.4 lbs, 7.44 kgs |
| MATERIALS OF CONSTRUCTION | |
| Coil Construction | Copper voice coil |
| Coil Former | Polyimide former |
| Magnet Composition | Ferrite magnet |
| Core Details | Vented core |
| Basket Materials | Die-cast aluminum basket |
| Cone Composition | Paper cone |
| Cone Edge Composition | Cloth cone edge |
| Dust Cap Composition | Solid composition paper dust cap |
