JL Audio 12TW3 | 12" 400W RMS Shallow Subwoofer DVC
JL Audio 12TW3 | 12" 400W RMS Shallow Subwoofer DVC - Dual 4 Ohm is backordered and will ship as soon as it is back in stock.
Buy with confidence
Verify fitment, selected options, availability and included components before checkout. Secure payment options and order confirmation are provided at checkout.
Description
Description
General Specifications
| Continuous Power Handling (RMS) | 400 W |
| Recommended Amplifier Power (RMS) | 200 - 400 W |
| Nominal Impedance (Znom) | Dual 4/8 Ω |
Physical Specifications
| Nominal Diameter | 12 in / 300 mm |
| Overall Diameter (A) | A1: 13.2 in / 335 mm A2: 12.5 in / 318 mm |
| Mounting Hole Diameter (B) | 11.625 in / 295 mm |
| Bolt Hole Circle Diameter (C) | 12.5 in / 318 mm |
| Motor Outer Diameter (D) | 6.125 in / 156 mm |
| Mounting Depth (E) | 3.5 in / 89 mm |
| Driver Displacement | 0.029 cu ft / 0.82 L |
| Net Weight | 14.9 lb / 6.8 kg |
Parameters
| Free Air Resonance (Fs) | 26.46 Hz |
| Electrical “Q” (Qes) | 0.558 |
| Mechanical “Q” (Qms) | 10.766 |
| Total Speaker “Q” (Qts) | 0.531 |
| Equivalent Compliance (Vas) | 1.72 cu ft / 48.73 L |
| One-Way Linear Excursion (Xmax)* | 0.6 in / 15.2 mm |
| Efficiency (1 W / 1 m)** | 84.11 dB SPL |
| Effective Piston Area (Sd) | 83.517 sq in / 0.0539 sq m |
Sealed Enclosure Specifications
| Wall Thickness | 0.75 in / 19 mm |
| Front Baffle Thickness | 0.75 in / 19 mm |
| Volume (net int.) | 0.80 cu ft / 22.7 L |
| External Width (W) | 21.25 in / 540 mm |
| External Height (H) | 16 in / 406 mm |
| External Depth (D) | 6.5 in / 165 mm |
| F3 | 37.99 Hz |
| Fc | 46.97 Hz |
| Qtc | 0.9426 |
Ported Enclosure Specifications
| Wall Thickness | 0.75 in / 19 mm |
| Front Baffle Thickness | 0.75 in / 19 mm |
| Volume (net int.) | 0.95 cu ft / 26.9 L |
| External Width (W) | 30 in / 762 mm |
| External Height (H) | 16.625 in / 422 mm |
| External Depth (D) | 6.50 in / 165 mm |
| Internal Slot Port Width (SW) | 5 in / 127 mm |
| Internal Slot Port Height (SH) | 2.50 in / 64 mm |
| Internal Slot Port Length (SL) | 31.25 in / 794 mm |
| Port Extension Length (EL) | 26 in / 660 mm |
| Tuning Frequency (Fb) | 32.14 Hz |
| F3 | 32.52 Hz |
