SKU: JL-6W3v3-4

JL Audio 6W3v3 | 6.5" 150W RMS Subwoofer SVC

No reviews yet. Bought this? Write the first review
Regular price $319.99
Shipping calculated at checkout.

Coil Configuration

Shipping & delivery

Usually ships in 2–3 business days unless a different lead time is shown on this page. Shipping cost is calculated at checkout (UPS or USPS to the contiguous U.S.).

Shipping policy · Returns · Fitment questions? (561) 207-7988

Delivery and Shipping

Standard order processing is 2–3 business days unless this product or your order confirmation states a different lead time. Custom-built, made-to-order, backorder, and pre-order items follow their stated lead times.

Enclosures and subwoofer boxes ship for $50 per unit. Other shipping charges are calculated at checkout. Orders outside the contiguous 48 United States may require additional shipping; we will contact you for approval before shipment.

Subwoofer boxes ship UPS Ground where available. Read our Shipping Policy and Return and Refund Policy for delivery, product-specific return windows, and warranty details.

Description


Continuous Power Handling (RMS) 150 W
Recommended Amplifier Power (RMS) 50 - 150 W
Nominal Impedance (Znom) 4 Ω or 2 Ω



Physical Specifications


Nominal Diameter 6.5 in / 165 mm
Overall Diameter (A) 6.85 in / 174 mm
Mounting Hole Diameter (B) 5.5 in / 140 mm
Bolt Hole Circle Diameter (C) 6.125 in / 156 mm
Motor Outer Diameter (D) 4.25 in / 108 mm
Mounting Depth (E) 4.25 in / 108 mm
Driver Displacement 0.02 cu ft / 0.57 L
Net Weight 6.1 lb / 2.8 kg



Parameters

Free Air Resonance (Fs) 41.80 Hz
Electrical “Q” (Qes) 0.533
Mechanical “Q” (Qms) 11.027
Total Speaker “Q” (Qts) 0.508
Equivalent Compliance (Vas) 0.181 cu ft / 5.13 L
One-Way Linear Excursion (Xmax)* 0.35 in / 8.89 mm
Reference Efficiency (no) 0.07%
Efficiency (1 W / 1 m)** 80.49 dB SPL
Effective Piston Area (Sd) 17.36 sq in / 0.0112 sq m
DC Resistance (Re) 3.476 Ω
