SURECOM SW-32UV

The SURECOM SW-32UV is a versatile analog RF meter designed for VHF and UHF frequencies, offering accurate measurements of forward and reflected power, as well as Voltage Standing Wave Ratio (VSWR). It's suitable for amateur radio operators and technicians working within the 125–525 MHz range.

📊 Key Specifications

• Frequency Range: 125–525 MHz

• Power Measurement Range: 0.2W to 100W

• Power Scales: 10W and 100W

• Accuracy:

  • ±10% at 10W

  • ±5% at 100W

• VSWR Measurement: Requires a minimum of 2W for full-scale deflection

• Impedance: 50Ω

• Connectors: SO-239 (UHF female)

• Dimensions: 76 mm (W) × 100 mm (H) × 10.5 mm (D)

• Power Source: Manual operation; no internal batterySurecom+6Surecom+6Surecom+6Surecom+6Surecom+6409 Shop+6Surecom+1409 Shop+1Surecom+4409 Shop+4Surecom+4Surecom

🔧 Features & Operation

• Meter Display: Analog scale for forward and reflected power in watts, and SWR ratio.

• Zero Adjustment: Mechanical knob to calibrate the needle.

• Range Switch: Selects between 10W and 100W power scales.

• Mode Switches:

  • Blue Switch: Selects between POWER and SWR functions.

  • Red Switch: Chooses between forward (FWD) and reflected (REF) power for POWER mode; sets SWR or measures SWR in SWR mode.

• SWR Calibration: SWR SET knob adjusts full-scale deflection when measuring VSWR.

• Connectors: SO-239 for both antenna and transmitter connections.
